– 42 –
Unit EF5200DE/YG5200D
Type Air cooled 4-stroke gasoline OHV
Cylinder Arrangement Inclined, 1 cylinder
Displacement cm
3
357
Bore × Stroke mm (in) 85.0 × 63.0
(3.35 × 2.48)
Operation Hours Hr 7.4
Fuel Unleaded gasoline
Fuel Tank Capacity L (Imp gal, US gal) 23.0 (5.06, 6.08)
Engine Oil Quantity L (Imp qt, US qt) 1.1 (0.97, 1.16)
Ignition System TCI
Spark Plug: Type BPR4ES (NGK)
Gap mm (in) 0.7 ~ 0.8 (0.028 ~ 0.031)
Noise Level* dB (A) 74.0
AE00701
SPECIFICATIONS
AE00702
Dimensions
Unit EF5200DE YG5200D
Overall Length mm (in) 894 (35.2) 670 (26.4)
Overall Width mm (in) 520 (20.5) 510 (20.1)
Overall Height mm (in) 527 (20.8) 577 (22.72)
Dry Weight kg (lb) 91 (201) 86 (190)
AE00704
Engine
* : Measured at rated operation from 7 m (23 ft) distance.
AE00707
Generator
Unit EF5200DE/YG5200D
AC Output
Rated voltage V 120/240
Rated frequency Hz 60
Rated current A 37.5/18.8
Rated output kVA 4.5
Safety Device: Type N.F.B.
Battery
Unit EF5200DE
Voltage V 12
Capacity Ah 26
7CB-F8199-11_b 07.12.22 10:16 Page 42
