DESCRIPTION
1 Carrying handles (shaded)
2 Fuel tank cap
3 Fuel level gauge
4 Fuel tank
5 Voltage adjuster
6 Ground (earth) terminal
7 Battery (For EF7200DE)
8 Oil filler cap
9 Oil drain bolt
0 Spark plug
q Fuel cock
w Recoil starter handle
e Air filter case cover
r Choke lever
t Muffler
EF7200DE
2
8
5
6
1 13 4
9
7
2
5
6
1
13 4
8
9
EF7200D
0 q
w
r
e
t
0 q
w
r
e
t
