– 8 –
1
2
CONTROL FUNCTION
Engine switch
The engine switch controls the ignition system.
1 “7” (ON)
Ignition circuit is switched on.
The engine can be started.
2 “5” (STOP)
Ignition circuit is switched off.
The engine will not run.
Oil warning light (Red)
When the oil level falls below the lower level, the oil
warning light comes on and then the engine stops
automatically. Unless you refill with oil, the engine will
not start again.
TIP
If the engine stalls or does not start, turn the engine
switch to “7” (ON) and then push the starter switch
(for EF7200DE) or pull the recoil starter. If the oil warn-
ing light flickers for a few seconds, the engine oil is
insufficient. Add oil and restart.
