– 11 –
Starter switch (For EF7200DE)
The starter switch controls the following item.
Push:
Starting circuit is switched on.
Release:
Starting circuit is switched off.
NOTICE
Take your hand off the switch immediately after the
engine starts.
Recoil starter
The recoil starter is used to start the engine.
Pull the recoil starter slowly until it is engaged, then
pull it briskly.
1 Recoil starter handle
NOTICE
9 Pull the recoil starter handle straight.
9 Return the recoil starter handle slowly.
9 Do not touch the recoil starter handle while the
generator is operating.
000-000
1
000-000
Voltage adjuster
The voltage adjuster is equipped for adjusting output
voltage to rated voltage.
TIP
Turn the voltage adjuster clockwise or counterclock-
wise to increase or decrease output voltage.
