– 49 –
For EF7200DE
A ENGINE DOES NOT START
B Turn the engine switch to “7” (ON), then
push the starter switch. And check if the
starter motor cranks.
C Cranks D Does not crank
F Push the starter switch, and check if the
oil warning light flickers.
G Does not flicker H Flickers
L Push the starter switch, and check the
spark plug for spark strength.
(See “WARNING”)
WARNING
9 To prevent FIRE HAZARDS be
sure fuel is not present in the
spark plug area.
9 To prevent FIRE HAZARDS be
sure to place the spark plug
as far way as possible from
the spark plug hole and carbu-
retor area.
9 To prevent ELECTRIC SHOCK
do not hold spark plug lead
with hand while testing.
M
OK
N Does not spark
X Consult a Yamaha dealer.
R Check the following.
9 Fuel line clogging
9 Air filter element clog-
ging
S Clogged
T OK
U
Clean
or
replace.
V OK
W Engine does not start.
7P6-F8199-13.indd 49 2019/12/11 9:57:30
To Next Page
