Components
36
EMU26201
Neutral interlock trigger
To shift out of neutral, first pull the neutral in-
terlock trigger up.
EMU26212
Neutral throttle lever
To open the throttle without shifting into either
forward or reverse, put the remote control le-
ver in the neutral position and lift the neutral
throttle lever.
IP:
The neutral throttle lever will operate only
when the remote control lever is in neutral.
The remote control lever will operate only
when the neutral throttle lever is in the closed
position.
EMU26233
Free accelerator
To open the throttle without shifting into either
forward or reverse, push the free accelerator
button and move the remote control lever.
IP:
●
The free accelerator button can only be
pushed when the remote control lever is in
the neutral position.
●
After the button is pushed, the throttle be-
gins to open after the remote control lever is
moved at least 35°.
●
After using the free accelerator, return the
remote control lever to the neutral position.
The free accelerator button will return auto-
matically to its set position. The remote con-
trol will then engage forward and reverse
normally.
EMU25913
Tiller handle (if equipped)
To change direction, move the tiller handle to
the left or right as necessary.
1. Neutral interlock trigger
1. Fully open
2. Fully closed
1. Fully open
2. Fully closed
3. Free accelerator
1
3
2
ZMU04575
