Instruments and indicators
57
fuel display. The chosen display is selected
using the “” (set) and “” (mode) but-
tons as described in this section.
After the main switch is first turned to the “”
(on) position, all of the displays come on as a
test. After a few seconds, the unit will change
to normal operation.
For more information, see the operation man-
ual for the meters.
1. Set button
2. Mode button
1. Fuel flow meter
2. Multifunction display
2
1
ZMU05438
1
2
ZMU05439
U63P1DE0.book Page 57 Tuesday, March 29, 2011 7:15 PM
