Yamaha F150D1 - Components; Components Diagram

Components
25
EMU2579Z
Components diagram
TIP:
* May not be exactly as shown; also may not be included as standard equipment on all models
(order from dealer).
1
2
4
3
6
7
9
10
2
5
8
11
ZMU08232
1. Top cowling
2. Cowling lock lever
3. Clamp bracket
4. Power trim and tilt unit
5. Anode
6. Cooling water inlet
7. Propeller*
8. Trim tab (anode)
9. Anti-cavitation plate
10.Flushing device
11.Fuse box
