4-17
E
EMU01743
CHECKING PROPELLER
WARNING
@
You could be seriously injured if the
engine accidentally starts while you are
near the propeller.
●
Before inspecting, removing or install-
ing the propeller, remove the spark
plug cap from the spark plug. Also, put
the shift control in Neutral and remove
the lanyard from the engine stop
switch.
●
Do not use your hand to hold the pro-
peller when loosening or tightening
the propeller nut. Put a wood block
between the cavitation plate and the
propeller to prevent the propeller from
turning.
@
EMU00390
Propeller Checking Point
●
Check each of the propeller blades for
wear, erosion from cavitation or ventila-
tion, or other damage.
●
Check the splines for wear and damage.
●
Check for fish line winding around the
propeller shaft.
●
Check the propeller shaft oil seal for dam-
age.
EMU00977
Removing the Propeller
1) Straighten the cotter-pin
1
and pull it
out using a pair of pliers.
2) Remove the propeller nut
2
and
washer
3
.
3) Remove the propeller
4
and thrust
washer
5
.
To Next Page
