Operation
64
switch while the boat is moving.
Adjust the outboard motor trim angle using
the power trim and tilt switch.
To raise the bow (trim-out), press the switch
“” (up).
To lower the bow (trim-in), press the switch
“ ” (down).
Make test runs with the trim set to different
angles to find the position that works best for
your boat and operating conditions.
EMU27912
Adjusting boat trim
When the boat is on plane, a bow-up attitude
results in less drag, greater stability and effi-
ciency. This is generally when the keel line of
the boat is up about 3 to 5 degrees. With the
bow up, the boat may have a greater tenden-
cy to steer to one side or the other. Compen-
sate for this as you steer. When the bow of
the boat is down, it is easier to accelerate
from a standing start onto plane.
1. Power trim and tilt switch
1. Power trim and tilt switch
1. Power trim and tilt switch
1. Power trim and tilt switch
