Yamaha FJR1300A(V) - Setup and Predelivery Checklist; Installation of Parts from Crate; Tightening Torque Specifications; Adjustments

–9–
EAA00090
FJR1300A(V) 2006
SETUP AND PREDELIVERY CHECKLIST
NOTE:
_
Check the following items again after setup and predelivery service have been completed.
A: INSTALLATION OF THE PARTS INCLUDED IN THE CRATE
à Steering stem nut à Windshield
à Grip ends à Battery
Ã
Front wheel
Ã
Front cowling left inner panel 2
Ã
Front fender
Ã
Front cowling right inner panel 2
à Front brake hose holders à Front cowling left inner panel 1
à Rearview mirrors à Front cowling right inner panel 1
B: TIGHTENING TORQUE OF EACH PART
à Steering stem nut 115 Nm (11.5 m · kg, 85 ft · lb)
Ã
Front wheel axle bolt 91 Nm (9.1 m · kg, 66 ft · lb)
Ã
Front wheel axle pinch bolt 21 Nm (2.1 m · kg, 15 ft · lb)
à Front brake caliper bolt 40 Nm (4.0 m · kg, 29 ft · lb)
Ã
Front wheel sensor bolt 30 Nm (3.0 m · kg, 22 ft · lb)
Ã
Front brake hose holder bolt 7 Nm (0.7 m · kg, 5.1 ft · lb)
Ã
Battery holder bolt 10 Nm (1.0 m · kg, 7.2 ft · lb)
C: ROUTING OF WIRE, CABLES, ETC.
Ã
Clutch cable
Ã
Unified brake hose
Ã
Front brake hoses
Ã
Negative battery lead
Ã
Throttle cables
Ã
Front wheel sensor lead
Ã
Positive battery lead
D: ADJUSTMENTS
Ã
Checking and charging the battery
Ã
Checking the brake fluid level
Ã
Measuring the tire pressure
Ã
Bleeding the hydraulic brake system
Ã
Checking the engine oil level
Ã
Adjusting the clutch lever
Ã
Checking the final gear oil level
Ã
Checking the clutch fluid level
à Checking the coolant level à Bleeding the hydraulic clutch system
Ã
Adjusting the engine idling speed
Ã
Adjusting the front fork legs
à Adjusting the throttle cable free play à Adjusting the rear shock absorber assembly
à Adjusting the front brake à Adjusting the headlight beams
Ã
Adjusting the rear brake
Ã
Adjusting the digital clock
à Adjusting the rear brake light switch
E: FUNCTION AND PERFORMANCE
à Check the function of the headlight, meter light and
taillight
à Check the function of the indicator on the speedom-
eter
à Check the function of the brake light à Check the feel of the brakes
à Check the function of the turn signal lights and in-
dicator lights
à Check engine for irregular noise (Yes/No)
à Check for exhaust leak (Yes/No)
Ã
Check the tone quality of the horn
F: ACCESSORIES, ETC. FOR DELIVERY
à Owner’s manual à Owner’s tool kit
