Yamaha FJR1300A(V) - Tightening Torques; Engine; Chassis

–73–
EAA10300
TIGHTENING TORQUES
Item Thread size
Tightening torque
Nm m · kg ft · lb
Engine:
Spark plug M10 13 1.3 9.4
Engine oil drain bolt M14 43 4.3 31
Chassis:
Final gear oil drain bolt M14 23 2.3 17
Engine mounting bolts (right front lower side) M12 49 4.9 35
Engine mounting bolts (right front upper side) M12 49 4.9 35
Engine mounting bolts (left front lower side) M12 49 4.9 35
Engine mounting bolts (left front upper side) M12 49 4.9 35
Engine mounting nut (rear upper side) M10 45 4.5 32
Spacer bolt M16 18 1.8 13
Engine mounting bolt (rear lower side) M10 45 4.5 32
Engine mounting bolt (left rear side) M8 16 1.6 11
Engine bracket bolt (left rear side) M10 32 3.2 23
Left footrest assembly bolt M10 49 4.9 35
Pinch bolt (front side) M8 24 2.4 17
Pinch bolt (rear side) M8 24 2.4 17
Engine bracket bolt (top side) M8 16 1.6 11
Engine mounting bolt (top side) M10 37 3.7 27
T-bar bolt M10 37 3.7 27
Hydraulic unit bracket bolt M6 11 1.1 8.0
Swingarm pivot shaft M28 23 2.3 17
Relay arm nut (relay arm and frame) M10 40 4.0 29
Connecting arm nut (relay arm and connecting
arm)
M10 48 4.8 35
Connecting arm nut (connecting arm and swing-
arm)
M10 48 4.8 35
Rear shock absorber assembly upper nut M12 64 6.4 46
Rear shock absorber assembly lower nut M10 40 4.0 29
Swingarm pivot shaft ring nut M28 115 11.5 85
Swingarm pivot shaft nut M18 125 12.5 90
Swingarm pivot shaft ring nut retainer bolt M6 10 1.0 7.2
Rear shock absorber spring preload adjusting lever
nut
M6 7 0.7 5.1
Upper bracket pinch bolt M8 26 2.6 19
Steering stem nut M28 115 11.5 85
Handlebar bolt M8 23 2.3 17
Handlebar nut M12 65 6.5 47
Lower ring nut M30 See “NOTE” 1.
Front brake master cylinder holder bolt M6 10 1.0 7.2
Front brake hose union bolt (front brake master cyl-
inder side)
M10 30 3.0 22
Lower bracket pinch bolt M8 23 2.3 17
