Front cowling assembly nut M8 32 3.2 23
Windshield drive unit bolt M6 10 1.0 7.2
Lower bracket cover bolt M6 7 0.7 5.1
Brake hose joint bolt M6 7 0.7 5.1
Brake hose joint bracket bolt M6 7 0.7 5.1
Fuel tank and fuel tank bracket bolt (front side) M8 16 1.6 11
Fuel tank and fuel tank bracket bolt (rear side) M8 16 1.6 11
Fuel tank bracket bolt (front side) M6 10 1.0 7.2
Fuel tank bracket and fuel tank stay nut M8 16 1.6 11
Fuel tank bracket nut (rear side) M6 8 0.8 5.8
Rider seat lock assembly nut M6 7 0.7 5.1
Passenger seat lock assembly nut M6 7 0.7 5.1
Storage compartment bolt M6 7 0.7 5.1
Rear carrier bolt M8 21 2.1 15
Front wheel axle bolt M14 91 9.1 66
Front wheel axle pinch bolt M8 See “NOTE” 2.
Rear wheel axle nut M18 125 12.5 90
Front brake caliper bolt M10 40 4.0 29
Rear brake torque rod nut M8 30 3.0 22
Front brake disc bolt M6 18 1.8 13
Rear brake disc bolt M6 18 1.8 13
Bleed screw (front brake caliper) M8 6 0.6 4.3
Bleed screw (rear brake caliper) M8 6 0.6 4.3
Rear wheel axle pinch bolt M8 23 2.3 17
Front wheel sensor bolt M8 30 3.0 22
Rear wheel sensor bolt M8 30 3.0 22
Hydraulic unit nut M8 16 1.6 11
Metering valve bolt M6 7 0.7 5.1
Brake hose union bolt (hydraulic unit) M10 30 3.0 22
Proportioning valve bolt M6 7 0.7 5.1
Brake hose flare nut (hydraulic unit) M10 19 1.9 13
Rear fender bolt M6 7 0.7 5.1
Sidestand nut M10 58 5.8 42
Brake pedal pinch bolt M6 8 0.8 5.8
Left footrest assembly bolt M8 28 2.8 20
Muffler stay bolt M8 28 2.8 20
Rear brake master cylinder bolt M8 18 1.8 13
Rear brake hose union bolt M10 30 3.0 22
Sidestand bolt M10 65 6.5 47
Centerstand bracket nut M10 55 5.5 40
Centerstand nut M10 55 5.5 40
Footrest cover bolt M8 16 1.6 11
Passenger footrest bracket bolt M8 16 1.6 11
Passenger footrest bolt M6 9 0.9 6.5
Item Thread size
Tightening torque
Nm m · kg ft · lb
