3-53
GB
EMU01573
PROCEDURE FOR TILTING UP
Power tilt models
1) Disconnect the fuel line or close the fuel
cock.
2) Push the power tilt switch “UP” until the
outboard has tilted up completely.
3) Push the tilt support knob into the clamp
bracket to support the engine.
WARNING
@
●
After tilting the engine, be sure to sup-
port it with the tilt support knob. Oth-
erwise, the engine could fall back
down suddenly if oil in the power tilt
unit should lose pressure.
●
Never operate the engine while it is
supported by the tilt support knob.
@
EMU01313
PROCEDURE FOR TILTING DOWN
Power tilt model
1) Push the power tilt switch “UP” until the
engine is supported by the tilt rod.
2) Pull out the tilt support knob.
3) Push the power tilt switch “DN” (Down)
to lower the engine to the desired posi-
tion.
U68T73A0.book Page 53 Sunday, March 30, 2003 6:34 PM
