4-3
GB
Model
Item
Unit FT8DE
DIMENSIONS
Overall length mm (in.) 552 (21.7)
Overall width mm (in.) 312 (12.3)
Overall height L/X mm (in.) 1,187 (46.7)/1,255 (49.4)
Transom height L/X mm (in.) 557 (21.9)/625 (24.6)
Weight L/X kg (lb.) 44 (97)/45 (99)
PERFORMANCE
Full throttle operating range r/min 5,000–6,000
Maximum output kW@r/min 5.9 @ 5,500
Idling speed (in neutral) r/min 1,000–1,100
ENGINE
Type 4-stroke, L2
Displacement cm
3
(cu.in.) 197 (12.02)
Bore
×
stroke mm (in.) 56.0
×
40.0 (2.20
×
1.57)
Ignition system CDI system
Spark plug NGK BR6HS-10
Spark plug gap mm (in.) 0.9–1.0 (0.035–0.039)
Control system Remote control
Starting system Electric start
Valve clearance (cold engine) IN mm (in.) 0.15–0.20 (0.006–0.008)
EX mm (in.) 0.20–0.25 (0.008–0.010)
Battery
Min. cold cranking amps (CCA/EN) amps at -18°C (-0.4°F) 347
Min. rated capacity (20HR/IEC) A·h40
Alternator output V-A (W) 12 - 6
Starting carburation system Choke start
DRIVE UNIT
Gear positions Forward-Neutral-Reverse
Gear ratio 2.92 (38/13)
Trim and tilt system Manual tilt
Propeller mark R
FUEL AND OIL
Recommended fuel Regular unleaded gasoline
R.O.N. Minimum 90
Fuel tank capacity L (US gal, Imp gal) 12 (3.17, 2.64)/25 (6.60, 5.50)
Recommended engine oil 4 stroke motor oil
API SE, SF, SG, SH, SJ
SAE 10W-30, 10W-40
Engine oil capacity (excluding oil filter) L (US qt, Imp qt) 0.8 (0.85, 0.70)
(including oil filter) L (US qt, Imp qt) —
Recommended gear oil Hypoid gear oil (SAE 90)
Gear oil capacity cm
3
(US oz, Imp oz) 370 (12.51, 13.05)
TIGHTENING TORQUE
Spark plug N·m (kgf·m, lb·ft) 24 (2.4, 17)
Propeller nut N·m (kgf·m, lb·ft) 21 (2.1, 15)
Engine oil drain bolt N·m (kgf·m, lb·ft) 24 (2.4, 17)
Engine oil filter N·m (kgf·m, lb·ft) —
