PERIODIC MAINTENANCE AND MINOR REPAIR
6-38
6
EAU43000
Replacing a turn signal light
bulb
1. Remove the turn signal light unit
by removing the screw.
2. Remove the socket (together with
the bulb) by turning it counter-
clockwise.
3. Remove the defective bulb by pull-
ing it out.
4. Insert a new bulb into the socket.
5. Install the socket (together with the
bulb) by turning it clockwise.
6. Install the turn signal light unit by
installing the screw.
CAUTION:
ECA11190
Do not overtighten the screw, other-
wise the lens may break.
1. Screw
2. Turn signal light unit
1. Turn signal light bulb socket
1. Turn signal light bulb
