APPENDIX ➤ Specifications En 79
Input jacks
• Analog Audio
Audio x 4 (AV 5, AUDIO 1–2, V-AUX [Mini Jack])
• Digital Audio (Supported frequencies: 32 kHz to 96 kHz)
Optical x 2 (AV 1, AV 4)
Coaxial x 2 (AV 2–3)
•Video
Composite x 4 (AV 3–5, V-AUX)
Component x 2 (AV 1–2)
• HDMI Input
HDMI x 4 (HDMI 1–4)
•Other
USB x 1 (USB2.0)
Output jacks
• Analog Audio
Speaker out x 5 (FRONT L/R, CENTER, SURROUND L/R)
Subwoofer Out x 1
AV OUT x 1
AUDIO OUT x 1
Headphone x 1
•Video
MONITOR OUT
- Component x 1
- Composite x 1
AV OUT
- Composite x 1
• HDMI Output
HDMI OUT x 1
HDMI
• HDMI Specification: Deep Color, “x.v.Color,” Auto Lip Sync,
ARC (Audio Return Channel), 3D, 4K
• Video Format (Repeater Mode)
-VGA
- 480i/60 Hz
- 576i/50 Hz
- 480p/60 Hz
- 576p/50 Hz
- 720p/60 Hz, 50 Hz
- 1080i/60 Hz, 50 Hz
- 1080p/60 Hz, 50 Hz, 24 Hz
- 3840 x 2160p/30 Hz, 25 Hz, 24 Hz
- 4096 x 2160p/24 Hz
• Audio Format
- Dolby Digital
-DTS
- DSD 6ch
- Dolby Digital Plus
-Dolby TrueHD
- DTS-HD High Resolution Audio
- DTS-HD Master Audio
- DTS Express
- PCM 2ch to 8ch (Max 192 kHz/24 bit)
• Content Protection: HDCP compatible
• Link Function: CEC supported
TUNER
• Analog Tuner
[U.K. and Europe models]
FM/AM with Radio Data System x 1 (TUNER)
[Other models]
FM/AM x 1 (TUNER)
USB
• Capable of iPod, Mass Storage Class USB Memory
• Current Supply Capacity: 1 A
Compatible Decoding Formats
• Decoding Format
- Dolby TrueHD, Dolby Digital Plus
- Dolby Digital
- DTS-HD Master Audio, DTS-HD High Resolution Audio,
DTS Express
- DTS, DTS 96/24, DTS-ES Matrix 6.1, DTS-ES Discrete 6.1
• Post Decoding Format
- Dolby Pro Logic
- Dolby Pro Logic II Music, Dolby Pro Logic II Movie,
Dolby Pro Logic II Game
- DTS Neo:6 Music, DTS Neo:6 Cinema
Audio Section
• Rated Output Power (1-channel driven)
[U.S.A. and Canada models] (1 kHz, 0.9% THD, 8 )
[Other models] (1 kHz, 0.9% THD, 6 )
Front L/R.....................................................................100 W/ch
Center ........................................................................100 W/ch
Surround L/R ..............................................................100 W/ch
• Rated Output Power (2-channel driven)
[U.S.A. and Canada models] (1 kHz, 0.9% THD, 8 )
Front L/R................................................................. 85 W+85 W
Center ...............................................................................85 W
Surround L/R .......................................................... 85 W+85 W
• Maximum Effective Output Power (JEITA, 1 kHz, 10% THD, 6  )
[Korea, Asia and General models]
Front L/R.....................................................................135 W/ch
Center ........................................................................135 W/ch
Surround L/R ..............................................................135 W/ch
• Dynamic Power (IHF)
[U.S.A. and Canada models]
Front L/R (8/6/4/2 ) ..................................110/130/160/180 W
[Other models]
Front L/R (6/4/2 ) ............................................110/130/150 W
Specifications

Yamaha HTR-3066 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Total Harmonic Distortion (THD)	0.9 %
Dynamic power per channel (4 Ohm)	160 W
Dynamic power per channel (8 Ohm)	110 W
Power output per channel (1KHz@8 Ohm)	100 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	4
AC (power) in	Yes
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Ethernet LAN	No
Product color	Black
Audio decoders	Dolby TrueHD, DTS Digital Plus, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
Power consumption (standby)	0.3 W
Package weight	10000 g

Weight and Dimensions

Depth	314.3 mm
Width	435 mm
Height	152.4 mm
Weight	7394 g
