Yamaha IPA8200 - Page 58

12
IPA8200
REF NO.
PART NO. DESCRIPTION
部品名
REMARKS
QTY RANK
* D202 WT886100 LED GREEN SEL6410E D LF
ＬＥＤ 緑
CH B SIGNAL 412429
D203 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH B PROTECT 411467
D204 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH B CLIP 411467
D301 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH C MUTE 411467
* D302 WT886100 LED GREEN SEL6410E D LF
ＬＥＤ 緑
CH C SIGNAL 412429
D303 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH C PROTECT 411467
D304 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH C CLIP 411467
D305 WJ598200 LED ORANGE SEL6910A D LF
ＬＥＤ 橙
CH C/D BRIDGE 446160 03
D306 WJ598200 LED ORANGE SEL6910A D LF
ＬＥＤ 橙
CH C/D PARA 446160 03
D401 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH D MUTE 411467
* D402 WT886100 LED GREEN SEL6410E D LF
ＬＥＤ 緑
CH D SIGNAL 412429
D403 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH D PROTECT 411467
D404 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH D CLIP 411467
D501 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH E MUTE 411467
* D502 WT886100 LED GREEN SEL6410E D LF
ＬＥＤ 緑
CH E SIGNAL 412429
D503 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH E PROTECT 411467
D504 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH E CLIP 411467
D505 WJ598200 LED ORANGE SEL6910A D LF
ＬＥＤ 橙
CH E/F BRIDGE 446160 03
D506 WJ598200 LED ORANGE SEL6910A D LF
ＬＥＤ 橙
CH E/F PARA 446160 03
D601 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH F MUTE 411467
* D602 WT886100 LED GREEN SEL6410E D LF
ＬＥＤ 緑
CH F SIGNAL 412429
D603 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH F PROTECT 411467
D604 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH F CLIP 411467
D701 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH G MUTE 411467
* D702 WT886100 LED GREEN SEL6410E D LF
ＬＥＤ 緑
CH G SIGNAL 412429
D703 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH G PROTECT 411467
D704 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH G CLIP 411467
D705 WJ598200 LED ORANGE SEL6910A D LF
ＬＥＤ 橙
CH G/H BRIDGE 446160 03
D706 WJ598200 LED ORANGE SEL6910A D LF
ＬＥＤ 橙
CH G/H PARA 446160 03
D801 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH H MUTE 411467
* D802 WT886100 LED GREEN SEL6410E D LF
ＬＥＤ 緑
CH H SIGNAL 412429
D803 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH H PROTECT 411467
D804 AAX6401R LED RED SEL6210R D LF
ＬＥＤ 赤
CH H CLIP 411467
EP100 XX698880 LUG TERMINAL MET37-0001
ラグ端子
075878 02
IC101 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
IC102 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
* IC103 YA884A00 IC NJU4066BV(TE1)
ＩＣ
ANALOG SWITCH 484456
IC202 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
* IC203 YA884A00 IC NJU4066BV(TE1)
ＩＣ
ANALOG SWITCH 484456
IC301 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
IC302 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
* IC303 YA884A00 IC NJU4066BV(TE1)
ＩＣ
ANALOG SWITCH 484456
IC402 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
* IC403 YA884A00 IC NJU4066BV(TE1)
ＩＣ
ANALOG SWITCH 484456
IC501 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
IC502 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
* IC503 YA884A00 IC NJU4066BV(TE1)
ＩＣ
ANALOG SWITCH 484456
IC602 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
* IC603 YA884A00 IC NJU4066BV(TE1)
ＩＣ
ANALOG SWITCH 484456
IC701 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
IC702 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
* IC703 YA884A00 IC NJU4066BV(TE1)
ＩＣ
ANALOG SWITCH 484456
IC802 AAX6275R IC NJM2068M-D TE1
ＩＣ
OP AMP 070170 04
* Q101 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q102 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q201 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q202 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q301 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q302 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q401 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q402 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q501 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q502 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q601 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q602 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q701 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q702 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q801 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
* Q802 WR970400 TRANSISTOR 2SC5938A
トランジスタ
484462
R101 AAX6288R CARBON RESISTOR (CHIP) 10K J
チップ抵抗
067497 03
FRONT
✽
: New Parts RANK: Japan only
