Yamaha KT100SEC - ENGINE DISASSEMBLY - CYLINDER AND PISTON; REMOVING CYLINDER HEAD AND CYLINDER; REMOVING PISTON AND PISTON RING; PISTON PIN REMOVAL CAUTIONS

4-4
ENG
DISASSEMBLINGTHEENGINE
2.Remove:
●
Smallendbearing
1.Remove:
●
Pistonpinclip
●
Pistonpin
●
Piston
DISASSEMBLINGTHEENGINE
REMOVINGTHEPISTONANDPISTONRING
1.Remove:
●
Sparkplug
●
Cylinderheadmountingnut
●
Cylinderhead
2.Remove:
●
Cylinderheadgasket
●
Cylindermountingnut
●
Cylinder
●
Cylindergasket
REMOVINGTHECYLINDERHEADANDCYLINDER
Pistonpinpuller:
90890-01304
●

Before removing piston pin clip, cover
crankcasewithacleanragtopreventpiston
pinclipfromfallingintocrankcasecavity.
●

Beforeremovingthepistonpin，deburrthe
clipgrooveandpinholearea．Ifthepiston
pin groove is deburred and piston pin is
stilldifficulttoremove，usethepistonpin
puller.
●

Donotuseahammertodrivethepiston.
CAUTION:
