Yamaha KT100SEC - ENGINE PARTS INSPECTION - CYLINDER HEAD; INSPECTING CYLINDER HEAD CARBON DEPOSITS; MEASURING CYLINDER HEAD WARPAGE; CYLINDER HEAD WARP LIMIT

4-9
ENG
CHECKINGTHEENGINEPARTS
CHECKINGTHEENGINEPARTS
CHECKINGTHECYLINDERHEAD
1.Inspect:
●
Carbondeposits
Usearoundedscraper
Avoidscratchingthealuminum.
Warplimit
0.015mm
2.Measure:
●
Cylinderheadwarpage
Outofspecification→Replace
CAUTION:
