Yamaha KT100SEC - ENGINE INSTALLATION - CLUTCH; INSTALLING CLUTCH WOODRUFF KEY; INSTALLING CLUTCH BODY; INSTALLING CLUTCH STUD BOLT

4-21
ENG
INSTALLINGTHEENGINE
INSTALLINGTHECLUTCH
1.Install:
●
Key(woodruffkey)
3.Install:
●
Studbolt(adaptershaft)
Applylockingagent(LOCTITE
R

)
2.Install:
●
Clutchbody
●

Installtheclutch bodywhiletakingnoteof
itsdirection.
2.Install:
●
Stay1mountingbolt
●
Stay1
●
Gear3mountingbolt
●
Gear3
●
Gear1
●
Idlegear
3.Install:
●
Crankcasecover2mountingbolt
●
Crankcasecover
Studbolt(adaptershaft)
2.5kg・m
Reference
Forinstallation,usethespecializedtool.
CAUTION:
