Yamaha KT100SEC - ENGINE DISASSEMBLY - CRANKCASE AND BEARINGS; REMOVING CRANKCASE BOLTS; SEPARATING CRANKCASES; REMOVING THE BEARING

4-8
ENG
DISASSEMBLINGTHEENGINE
3.Remove:
●
Rightcrankcase
Makesurethecrankseparatingtoolbodyis
parallelwiththecrankcase.
REMOVINGTHEBEARING
1.Remove:
●
Bearing
Forremovalofthebearing,twokindsoftools
are available.  Choose the appropriate one
dependingonhowthebearingisinstalled.
Fixedontheoutside→Bearingpuller
Fixedontheinside→Bearingpuller
4.Remove:
●
Leftcrankcase
●
Crankshaftassembly
Makesurethecrankseparatingtoolbodyis
parallelwiththecrankcase.
Crankcaseseparatingtool:
90890-01135
Takecaresothattheoilseallipisnotdamaged.
Crankcaseseparatingtool
90890-01135
Takecaresothattheoilseallipisnotdamaged.
2.Remove:
●
Bolt(crankcase)
CAUTION:
CAUTION:
