Yamaha KT100SEC - ENGINE INSTALLATION - CRANKCASE; CLEANING CRANKCASE SURFACES; INSTALLING DOWEL PINS; INSTALLING CRANKSHAFT AND RIGHT CRANKCASE

4-17
ENG
INSTALLINGTHEENGINE
INSTALLINGTHECRANKCASE
1. Clean the contacting surface of crankcase
(leftandright)beforeapplyingthesealant.
2.Install:
●
Dowelpin
Takecaresothattheoilseallipisnotdamaged.
3.Install:
●
Rightcrankcase
●
Crankshaft
Installthecrankshaftbyinstallingtools.
4.Applythesealant.
●
Leftcrankcase
Crankshaftinstallingpot
90890-01274
Crankshaftinstallingbolt
90890-01275
Adapter
90890-01278
CAUTION:
