Yamaha KT100SEC - ENGINE INSTALLATION - MAGNETO AND STARTER; INSTALLING THE TCI MAGNETO; INSTALLING THE STARTER MOTOR; IGNITION TIMING ADJUSTMENT REFERENCE

4-20
ENG
INSTALLINGTHEENGINE
INSTALLINGTHETCIMAGNETO
1.Temporarilyinstall:
●
Plate
2.install:
●
Woodruffkey
●
Rotor
Wheninstallingtherotor, alignthekeywayof
therotorwiththewoodruffkey.
Tightenallboltsin2〜3stepsandbesureto
tighteninnumberedorderasshown.
4.Install:
●
Cylinderhead
6.Temporarilyinstall:
●
Coilassembly
7.
Adjusttheairgapandtightenthecoilassembly.
Cylinderhead
1.8〜2.3kg・m
INSTALLINGTHESTARTERMOTOR
1. Installthestartermotortothecrankcasecover1  . 
●
Startermotormountingbolt
●
Startermotor

2.Install:
●
Crankcasecover1mountingbolt
●
Crankcasecover1
3.Install:
●
Rotornut
4.Adjusttheignitiontiming.
(RefertotheCHAPTER3.)
5.Tightentheplate.
Rotornut
3.0〜4.0kg・m
Airgap
0.4mm
