Yamaha KT100SEC - CARBURETOR REASSEMBLY AND CHECK; CARBURETOR REMOVAL POINTS; CHECKING THE CARBURETOR; METERING LEVER ADJUSTMENT

5-5
CARB
CARBURETOR
Alwayscleanupspilledfuelimmediately.
NOTE:
1.Disconnect:
●
Fuelhose
●
Negativepressurehose
●
Throttlecable
REMOVALPOINTS
REMOVINGTHECARBURETOR
2.Remove:
●
Airbox
●
Carburetor
Plugthefuelhosesothatfueldoesnotrunout.
1.Inspect:
●
Floatchamberbody
Blowoutallpassagesandjetswithcompressed
air.
CHECKINGTHECARBURETOR
Neveruseawire.
1.Inspect:
●
Meteringleverdistance
2.Adjust:
●
Meteringlever
Bendtheribofthemeteringlever.
ASSEMBLINGTHECARBURETOR
Standardmeteringleverdistance
0.13〜0.25mm
Outofspecification→Adjust.
WARNING
CAUTION:
