4-22
ENG
INSTALLINGTHEENGINE
4.Tighten:
●
M8stopperscrew(stopdowel)
Applylockingagent(LOCTITE
R

)
6.Install:
●
Clutchdrum
7.Install:
●
Spacer
●
Circlip(seegerring)
Afterinstallingtheclutchdrum,checkforsmooth
movement.
M8stopperscrew(stopdowel)
2.0kg・m
5.Tighten:
●
Thrustwasher(shim)
●
Rollergauge
Applythegreaseontotherollergauge.
CAUTION:
