Components
24
EMU46722
Components diagram
TIP:
* May not be exactly as shown; also may not be included as standard equipment on all models
(order from dealer).
1
2
3
4
5
6
10
11
12
F115, LF115
F130, LF130
12
8
9
7
1. Top cowling
2. Cowling lock lever
3. Power trim and tilt unit
4. Clamp bracket
5. Anode
6. Cooling water inlet
7. Propeller*
8. Trim tab (anode)
9. Anti-cavitation plate
10.Flushing device
11.Power trim and tilt switch
12.Fuse box
