Trouble Recovery
104
EMU29529
Power trim and tilt will not operate
EWM02331
Never get under the engine while it is tilt-
ed. Severe injury could occur if the out-
board motor accidentally falls.
If the outboard motor cannot be tilted
up/down using the power trim and tilt unit,
e.g. because of a discharged battery or a fail-
ure with the unit itself, the outboard motor
can be tilted manually.
(1) Stop the engine.
(2) Loosen the manual valve screw by turn-
ing it counterclockwise until it stops.
(3) Adjust the outboard motor to a navigable
angle, tighten the manual valve screw
clockwise, and secure the outboard mo-
tor.
EMU44991
Water separator-alert is activated af-
ter leaving port
EWM01501
Gasoline is highly flammable, and its va-
pors are flammable and explosive.
Do not perform this procedure on a hot
or running engine. Allow the engine to
cool.
There will be fuel in the fuel filter. Keep
away from sparks, cigarettes, flames or
other sources of ignition.
This procedure will allow some fuel to
spill. Catch fuel in a rag. Wipe up any
spilled fuel immediately.
The fuel filter must be reassembled
carefully with the O-ring, filter cup, and
hoses in place. Improper assembly or
replacement could result in a fuel leak,
which could result in a fire or explosion
hazard.
If the water separator-alert indicator blinks or
the buzzer sounds intermittently, perform the
following procedure.
The buzzer sounds only when the remote
control lever is placed in neutral.
1. Manual valve screw
1. Water separator-alert indicator
