Yamaha LF200 - Procedure for Tilting down (Power Trim and Tilt Models); Shallow Water; Power Trim and Tilt Models

Operation
61
EMU42700
Procedure for tilting down (power trim
and tilt models)
1. Push the power trim and tilt switch “ ”
(up) until the outboard motor is supported
by the tilt rod and the tilt support lever be-
comes free.
2. Release the tilt support lever.
3. Push the power trim and tilt switch “ ”
(down) to lower the outboard motor to the
desired position.
EMU28062
Shallow water
EMU32871
Power trim and tilt models
The outboard motor can be tilted up partially
to allow operation in shallow water.
NOTICE
ECM01490
● If the engine speed is suddenly in-
creased when the outboard motor is par-
tially tilted up, the power trim and tilt unit
could be damaged.
●
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit
is above the surface of the water when
setting up for and cruising in shallow
water. Otherwise severe damage from
overheating can result.
EMU32922
Procedure for power trim and tilt models
1. Place the remote control lever in neutral.
DN
ZMU04196
ZMU04603
DN
N
ZMU04588
