9.14 Display Key Input for Dynamics Meters
When this preference is ON, the input meters displayed in the Dynamics
Processor thumbnails in the Mixer window will show the level of the Key Input
signal for every Dynamics Processor. If this preference is Off, the input signal
going into the Dynamics Processors will be displayed.
9.15 RTA Peak Hold Mode
An RTA Hold function is available in the PEQ and GEQ editing screens. The
mode for this function is selected in the Setup screen.
Freeze
When this mode is selected, the RTA display will “freeze” at the moment the
[RTA Hold] button is pressed.
All Peaks
When this mode is selected, the highest level for each RTA frequency band
will be displayed in red, behind the current RTA levels which are displayed in
grey.
High Peak
When this mode is selected, only the frequency band which has been
measured at the highest level will be displayed in red, behind the current RTA
levels which are displayed in grey.
9.16 RTA Input Gain
Input Gain or Attenuation can be applied to the RTA input signal in order to
allow the range of the RTA to be more usefully displayed within the PEQ or
GEQ editing screens. The following gain levels are available:
• -24dB
• -12dB
• 0dB
• 12dB
• 24dB
