Instrument and control functions
4-19
4
2. Install the rider seat bolts.
3. Install the center cover by install-
ing the screws.
4. Install the passenger seat.
Make sure that the seats are properly
secured before riding.
EAU62930
Helmet holders
The helmet holders are located on the
bottom of the passenger seat.
To secure a helmet to a helmet hold-
er
1. Remove the passenger seat. (See
page 4-18.)
2. Attach a helmet to a helmet hold-
er, and then securely install the
passenger seat. WARNING! Nev-
er ride with a helmet attached to
the helmet holder, since the hel-
met may hit objects, causing
loss of control and possibly an
accident.
[EWA10162]
1. Projection
2. Seat holder
1. Helmet holder
1. Helmet
2. Passenger seat
UB5W10E0.book Page 19 Friday, March 27, 2020 12:34 PM
