Yamaha MT03M - Vehicle Lights; Replacing the License Plate Light Bulb

Periodic maintenance and adjustment
7-33
7
EAU80380
Vehicle lights
Except for the license plate light bulb,
this model’s lights are all LED.
If an LED light does not come on,
check the fuses and then have a
Yamaha dealer check the vehicle. If the
license plate light does not come on,
check and replace the bulb. (See page
7-33.)
NOTICE
ECA16581
Do not affix any type of tinted film or
stickers to the headlight lens.
EAU62670
Replacing the license plate
light bulb
1. Remove the mudguard by remov-
ing the quick fasteners.
2. Remove the rear fender lower
panel by removing the bolts and
screws.
3. Remove the license plate light
bulb socket (together with the
bulb) by pulling it out.
4. Remove the burnt-out bulb by
pulling it out.
1. Headlight (high beam)
2. Headlight (low beam)
3. Auxiliary light
3
12
1. Mudguard
2. Quick fastener
1. Bolt
2. Screw
3. Rear fender lower panel
1
2
3
2
1
2
2
1
