MW10
■ INSPECTIONS
1. Scope
This inspection specification is applied to the mixer MW10.
2. Power Supply
The voltage is within +/-10%.
AC Adaptor shall be used.
Destination Voltage AC Adaptor
J 100V WC703400
U 120V WC703500
O 220V WC711000
K 220V WC703800
B 230V WC703700
H 230V WC703600
A 240V WC703900
3. Inspections
Cubase
3.1 Preparation
* Application software of USB AUDIO
Use the software that can be set as follows.
(Cubase LE, TWE, etc. Reffer to page 32 for the example in the Cubase LE Windows version.)
Sampling rate---48KHz or 44.1KHz
Resolution -------16 bits
* Unless otherwise specified, the input signal should be sine wave at 1kHz. The source impedance should be
150 ohms.
* The load resistance for each output terminals are as follows,
PHONE (L/ R) : 40 ohms (3W or more)
Others: 10 kohms
Unless otherwise specified, the operation elements shall be set as follows,
●
CH (1-2) INPUT
GAIN control : MAX (-60/-34dBu)
switch : OFF
EQ (HIGH, MID, LOW) level control : CENTER
AUX level control : PRE (turned counterclockwise fully)
PAN control : L (turned counterclockwise fully)
CH LEVEL VR : MAX
●
ST CH (3/4, 5/6)
GAIN control : MAX (-60/-34dBu)
switch : OFF
EQ (HIGH, MID, LOW) level control : CENTER
AUX level control : PRE (turned counterclockwise fully)
PAN/BAL control : L (turned counterclockwise fully)
CH LEVEL VR : MAX
●
ST CH (7/8, 9/10)
EQ (HIGH, MID, LOW) level control : CENTER
AUX level control : PRE (turned counterclockwise fully)
BAL control : L (turned counterclockwise fully)
CH LEVEL VR : MAX
To Next Page
