Yamaha MX-A5000 - Technical Specifications; Input and Output Specifications; General and Power Specifications

Appendix En 13
Specifications
Input jacks
•Audio
Analog RCA (Unbalance) x 11
Analog XLR (Balance) x 11 (1:GND, 2:HOT, 3:COLD)
Output jacks
•Audio
Speaker Out x 11 ch
(13 Terminals: CH.1, CH.2-A [L/R], CH.2-B [L/R], CH.3 [L/R] to
CH.6 [L/R])
Other jacks
• TRIGGER OUT x 1 (+12 V/0.1 A max.)
• TRIGGER IN x 1 (+12 V In)
• TRIGGER THROUGH OUT x 1
Audio Section
• Rated Output Power (2-channel driven)
(20 Hz to 20 kHz, 0.06% THD, 6 )
CH.1................................................................................ 170 W
CH.2 (L/R)....................................................................... 170 W
CH.3 (L/R)....................................................................... 170 W
CH.4 (L/R)....................................................................... 170 W
CH.5 (L/R)....................................................................... 170 W
CH.6 (L/R)....................................................................... 170 W
(20 Hz to 20 kHz, 0.06% THD, 8 )
CH.1................................................................................ 150 W
CH.2 (L/R)....................................................................... 150 W
CH.3 (L/R)....................................................................... 150 W
CH.4 (L/R)....................................................................... 150 W
CH.5 (L/R)....................................................................... 150 W
CH.6 (L/R)....................................................................... 150 W
(1 kHz, 0.9% THD, 8 )
CH.1................................................................................ 170 W
CH.2 (L/R)....................................................................... 170 W
CH.3 (L/R)....................................................................... 170 W
CH.4 (L/R)....................................................................... 170 W
CH.5 (L/R)....................................................................... 170 W
CH.6 (L/R)....................................................................... 170 W
• Rated Output Power (1-channel driven)
(1 kHz, 0.9% THD, 6 )
CH.1 ...........................................................................230 W/ch
CH.2 (L/R) ..................................................................230 W/ch
CH.3 (L/R) ..................................................................230 W/ch
CH.4 (L/R) ..................................................................230 W/ch
CH.5 (L/R) ..................................................................230 W/ch
CH.6 (L/R) ..................................................................230 W/ch
(1 kHz, 0.9% THD, 8 )
CH.1 ...........................................................................190 W/ch
CH.2 (L/R) ..................................................................190 W/ch
CH.3 (L/R) ..................................................................190 W/ch
CH.4 (L/R) ..................................................................190 W/ch
CH.5 (L/R) ..................................................................190 W/ch
CH.6 (L/R) ..................................................................190 W/ch
(1 kHz, 0.9% THD, 4 )
CH.2 (L/R) [U.K. and Europe models]........................290 W/ch
• Maximum Effective Output Power (1-channel driven, JEITA)
[China, Taiwan, Korea and Asia models]
(1 kHz, 10% THD, 6 )
CH.1 ...........................................................................280 W/ch
CH.2 (L/R) ..................................................................280 W/ch
CH.3 (L/R) ..................................................................280 W/ch
CH.4 (L/R) ..................................................................280 W/ch
CH.5 (L/R) ..................................................................280 W/ch
CH.6 (L/R) ..................................................................280 W/ch
(1 kHz, 10% THD, 8 )
CH.1 ...........................................................................230 W/ch
CH.2 (L/R) ..................................................................230 W/ch
CH.3 (L/R) ..................................................................230 W/ch
CH.4 (L/R) ..................................................................230 W/ch
CH.5 (L/R) ..................................................................230 W/ch
CH.6 (L/R) ..................................................................230 W/ch
• Dynamic Power (IHF)
1-channel driven (8/6/4/2 ) ......................190/250/350/500 W
• Damping Factor
All Channels, 1 kHz, 8  ....................................... 180 or more
• Input Sensitivity / Input Impedance
Unbalance (1 kHz, 100 W/8 ).............................. 1.0 V/47 k
Balance (1 kHz, 100 W/8 ) .................................. 2.0 V/47 k
• Maximum Input Signal
Unbalance (1 kHz, 0.5% THD, 8 ).....................1.3 V or more
Balance (1 kHz, 0.5% THD, 8 ) .........................2.6 V or more
• Frequency Response (10 Hz to 100 kHz)................... +0/-3 dB
• Total Harmonic Distortion (70 W/8 ) ............... 0.015% or less
• Signal to Noise Ratio (IHF-A Network)
(Input Shorted 1 k, Reference Level 150 W/8 )
......................................................................... 116 dB or more
• Residual Noise (IHF-A Network)
Speaker Out (Input Shorted)................................ 60 µV or less
• Channel Separation (Input 5.1 k Shorted , 1 kHz/10 kHz)
...................................................................... 90/75 dB or more
• Gain...............................................................................29.1 dB
General
• Power Supply
[U.S.A. and Canada models]..........................AC 120 V, 60 Hz
[Taiwan model]................................ AC 110 to 120 V, 50/60 Hz
[China model] ................................................. AC 220 V, 50 Hz
[Korea model] .................................................AC 220 V, 60 Hz
[Australia model]............................................. AC 240 V, 50 Hz
[U.K. and Europe models] .............................. AC 230 V, 50 Hz
[Asia model].................................... AC 220 to 240 V, 50/60 Hz
• Power Consumption
[U.S.A. and Canada models]..............................650 W/850 VA
[Korea model] .................................................................550 W
[Other models]................................................................650 W
• Standby Power Consumption ........................... 0.1 W (Typical)
• Maximum Power Consumption (All Channel driven, 10% THD)
[Taiwan and Asia models].............................................1500 W
• Power Consumption (No Signals) ...................... 75 W (Typical)
• Dimensions (W x H x D)
...................435 x 210 x 463.5 mm (17-1/8” x 8-1/4” x 18-1/8”)
* Including legs and protrusions
• Weight ...........................................................25.4 kg (56.0 lbs)
* Specifications are subject to change without notice.
