Yamaha Rhino 2006 User Manual

8 - 51
CHAS
STEERING SYSTEM
TIE-ROD AND STEERING KNUCKLE
3
6
8
9
7
4
2
5
New
3
New
New
LS
1
T
R
.
.
30 Nm (3.0 m
•
kg, 22 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
39 Nm (3.9 m
•
kg, 28 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
Order Job/Part Q’ty Remarks
Removing the tie-rod and steering
knuckle
Remove the parts in the order listed.
Front wheel/brake disc Refer to “FRONT WHEELS AND BRAKE
DISCS”.
1 Tie-rod 1
2 Brake disc guard 1
3Nut 2
4 O-ring 1
5 Brake hose holder bolt 1
6 Steering knuckle 1 Refer to “REMOVING THE STEERING
KNUCKLES”.
7 Circlip 1
8 Ball joint 1
9 Rubber boot 1
For installation, reverse the removal pro-
cedure.
