100 SPX2000—Owner’s Manual
Input/Output Characteristics
Analog Input Characteristics
*1 Sensitivity is the lowest level that will produce an output of +4dB(1.23V) or the nominal output level when the unit is
set to maximum gain.(level control is maximum position.)
*2 XLR-3-31 type connectors are balanced. (1=GND, 2=HOT, 3=COLD)
*3 Phone jacks are balanced. (Tip=HOT, Ring=COLD, Sleeve=GND)
*4 In these specifications, when dBu represents are specific voltage, 0 dBu is referenced to 0.775 Vrms.
*5 AD converter is 24-bit linear,128-times oversampling @Fs=44.1, 48 kHz, 64-times oversampling @Fs=88.2, 96 kHz
Analog Output Characteristics
*1 XLR-3-32 type connectors are balanced. (1=GND, 2=HOT, 3=COLD)
*2 Phone jacks are balanced. (Tip=HOT, Ring=COLD, Sleeve=GND)
*3 In these specifications, when dBu represents are specific voltage, 0 dBu is referenced to 0.775 Vrms.
*4 DA converter is 24-bit, 128-times oversampling @Fs=44.1, 48 kHz, 64-times oversampling @Fs=88.2, 96 kHz
Digital Input Characteristics
*1 XLR-3-31 type connectors are balanced. (1=GND, 2=HOT, 3=COLD)
Digital Output Characteristics
*1 channel status of AES/EBU OUT
type: 2 audio channels
emphasis: NO
sampling frequency: depends on the internal configuration
*2 dither: word length 16 - 24-bit
*3 XLR-3-32 type connector is balanced. (1=GND, 2=HOT, 3=COLD)
Control I/O Characteristics
Input Terminals Level SW
Input Level
VR.
Actual
Load
Impedance
For Use With
Nominal
Input Level
Connector
Sensitivity Nominal
Max.
before clip
INPUT L, R
+4 dBu
Max.:
+10 dB
10 k Ω
600 Ω
Lines
–6 dBu
(0.388 V)
—
+14 dBu
(3.88 V)
XLR-3-31 type
(Balanced)
Phone jack
(TRS: Balanced)
–10 dBu
Max.:
+10 dB
–20 dBu
(0.0775 V)
—
0 dBu
(0.775 V)
Input Terminals Level SW
Input Level
VR.
Actual
Load
Impedance
For Use With
Nominal
Input Level
Connector
Sensitivity Nominal
Max.
before clip
INPUT L, R
+4 dBu
Nominal:
0 dB
10 k Ω
600 Ω
Lines
—
+4 dBu
(1.23V)
+ 24 dBu
(12.28 V)
XLR-3-31 type
(Balanced)
Phone jack
(TRS: Balanced)
–10 dBu
Nominal:
0 dB
—
–10 dBu
(0.245V)
+10 dBu
(2.45 V)
Output Terminals
Actual
Source
Impedance
For Use With
Nominal
Level SW
Output Level
Connector
Nominal
Max.
before clip
OUTPUT L, R 150 Ω 600 Ω Lines
+4 dBu
+4 dBu
(1.23V)
+24 dBu
(12.28V) XLR-3-32 type (Balanced)
Phone jack (TRS: Balanced)
–10 dBu
–10 dBu
(0.245V)
+10 dBu
(2.45V)
Input Terminals Format Data Length Level Connector
AES/EBU IN AES/EBU 24-bit RS422 XLR-3-31 type (Balanced)
Output Terminals Format Data Length Level Connector
AES/EBU OUT AES/EBU Professional use 24-bit RS422 XLR-3-32 type (Balanced)
Terminals Format Level Connector
USB TO HOST USB 1.1 0 to 3.3 V B type USB Connector
MIDI
IN MIDI — DIN Connector 5P
OUT/THRU MIDI — DIN Connector 5P
WORD CLOCK IN — TTL/75 Ω BNC Connector
