SPX2000—Owner’s Manual 101
Electrical Characteristics
Input Level VR is nominal when measured. Output impedance of signal generator:600ohms
Frequency Response
Fs=48 kHz: @20 Hz-20 kHz, reference to the nominal output level @1 kHz
Fs=96 kHz: @20 Hz-40 kHz, reference to the nominal output level @1 kHz
Gain Error
@1 kHz
*1 In these specifications, when dBu represents are specific voltage, 0 dBu is referenced to 0.775 Vrms.
Total Harmonic Distortion
*1 In these specifications, when dBu represents are specific voltage, 0 dBu is referenced to 0.775 Vrms.
*2 Total Harmonic Distortion is measured with a 18 dB/octave filter @80 kHz.
Hum & Noise
Fs=48/96 kHz
*1 Hum & Noise are measured with a 6 dB/octave filter @12.7 kHz;
equivalent to a 20 kHz filter with infinite dB/octave attenuation.
*2 In these specifications, when dBu represents are specific voltage, 0 dBu is referenced to 0.775 Vrms.
Dynamic Range
Fs=48/96 kHz
*1 Dynamic range are measured with a 6 dB/octave filter @12.7 kHz;
equivalent to a 20 kHz filter with infinite dB/octave attenuation.
Crosstalk
@1 kHz
Maximum voltage gain
@1 kHz
Input Output RL Conditions Min Typ Max Units
INPUT L, R OUTPUT L, R 600 Ω — –3.0 0.0 +1.0 dB
Input Output RL Conditions Min Typ Max Units
INPUT L, R OUTPUT L, R 600 Ω
INPUT LEVEL SW: +4, OUTPUT LEVEL SW: +4 +2.0 +4.0 +6.0 dBu
INPUT LEVEL SW: –10, OUTPUT LEVEL SW: –10 –12.0 –10.0 –8.0 dBu
Input Output RL Conditions Min Typ Max Units
INPUT L, R OUTPUT L, R 600Ω
Fs=48 kHz: +14 dBu @20 Hz-20 kHz,
INPUT LEVEL SW: +4,
OUTPUT LEVEL SW: +4
0.05 %
Fs=96 kHz: +14 dBu @20 Hz-40 kHz,
INPUT LEVEL SW: +4,
OUTPUT LEVEL SW: +4
0.05 %
Input Output RL Conditions Min Typ Max Units
INPUT L, R OUTPUT L, R 600 Ω
Rs=600 Ω, INPUT LEVEL VR: nominal
INPUT LEVEL SW: +4 /OUTPUT LEVEL SW: +4
–80 dBu
Input Output RL Conditions Min Typ Max Units
INPUT L, R OUTPUT L, R 600 Ω AD + DA, INPUT LEVEL VR: max 106 dB
From/To To/From Conditions Min Typ Max Units
INPUT L, R OUTPUT L, R INPUT to OUTPUT –80 dB
Input Output RL Conditions Min Typ Max Units
INPUT L, R OUTPUT L, R 600 Ω
Rs=600 Ω, INPUT LEVEL VR: max
INPUT LEVEL SW: +4 /OUTPUT LEVEL SW: +4
+10 dB
