Yamaha Waverunner VXS VX1800 User Manual

5-19
Electrical box
Electrical box
No. Part name
Q
’ty
Remarks
1 Electrical box cover 1
2 Plastic tie 2
3Bolt 8
M6
× 25 mm
4ECM 1
5 Collar 8
6 Grommet 8
7 Fuse box 1
8Fuse 3 3 A
9 Fuse 4 10 A
10 Fuse 2 20 A
11 Fuse 2 30 A
12 Fuse 2 50 A
13 Relay 4 Main, fuel pump, ETV, SCU
14 Fuse puller 1
15 Bolt 2
M6
× 14 mm
16 Stay 1
5
6
4 Nm (0.4 kgf·m, 3.0 ft·lb)
20
19
18
27
4
3
1
2
2
5 Nm (0.5 kgf·m, 3.7 ft·lb) 5 Nm (0.5 kgf·m, 3.7 ft·lb)
5 Nm (0.5 kgf·m, 3.7 ft·lb)
5 Nm (0.5 kgf·m, 3.7 ft·lb)
25
26
24
23
22
21
5 Nm (0.5 kgf·m, 3.7 ft·lb)
5
6
7
3
14
13
11
10
11
10
9
8
9
9
13
12
13
12
17
15
15
16
21
SG
