Side cover
8-8
Side cover
No. Part name
Q
’ty
Remarks
1Nut 2
2 Screw 4
M6
× 25 mm
3 Outer ornament (left) 1
4 Outer ornament (right) 1
5 Cap (left) 1
6 Cap (right) 1
7 Inner ornament (left) 1
8 Inner ornament (right) 1
9Bolt 4
M6
× 29 mm
10 Nut 2
11 Screw 2
M6
× 18 mm
12 Side cover (left) 1
13 Side cover (right) 1
14 Nut 2
10
10
13
4
2
6
11
9
14
9
8
12
1
7
3
2
5
9
11
9
14
LT
572
LT
572
5.5 Nm (0.55 kgf
·
m, 4.06 ft
·
lb)
5.5 Nm (0.55 kgf
·
m, 4.06 ft
·
lb)
5.5 Nm (0.55 kgf
·
m, 4.06 ft
·
lb)
5.5 Nm (0.55 kgf
·
m, 4.06 ft
·
lb)
5.5 Nm (0.55 kgf
·
m, 4.06 ft
·
lb)
