2-1
Model data
Model data
Model code
Hull F2W
Engine 6EW
Jet pump 6EW
Dimensions and weight
Length VX1800-P 3340 mm (131.5 in)
VX1800A-P 3350 mm (131.9 in)
Width 1220 mm (48.0 in)
Height 1190 mm (46.9 in)
Dry weight VX1800-P 347 kg (765 lb)
VX1800A-P 348 kg (767 lb)
Maximum people on board 3 person
Maximum load capacity 240 kg (530 lb)
Performance
Maximum output 132.4 kW at 7600 r/min
Full throttle operating range 7600 r/min
Trolling speed 1300 ± 100 r/min
Maximum fuel consumption 48.7 L/h (12.9 US gal/h, 10.7 Imp.gal/h)
Cruising range at full throttle 1.44 hour
Engine
Engine type Liquid cooled 4-stroke, DOHC
Number of cylinders 4
Engine displacement 1812 cm³
Bore × stroke 86.0 × 78.0 mm (3.39 × 3.07 in)
Compression ratio 11.0 : 1
Exhaust system Wet exhaust
Lubrication system Wet sump
Cooling system Water
Starting system Electric
Camshaft drive system Chain drive
Timing chain tensioning system Automatic
Ignition system T.C.I.
Ignition timing BTDC25.0
Spark plug (NGK) LFR6A
Spark plug gap 0.8–0.9 mm (0.031–0.035 in)
Firing order 1–3–4–2
Oil filter type Cartridge type
Oil pump type Trochoid
Drive unit
Propulsion system Jet pump
Jet pump type Axial flow, single stage
Impeller rotation Counterclockwise
Transmission Direct drive from engine
Jet thrust nozzle angle 24.0+24.0°
Trim adjusting system Electrical 5 position
Jet thrust nozzle trim angle -6, -3, 0, 3, 6°
