Yamaha XMAX - Right View of the Scooter

%FTDSJQUJPO
3-2

EAU10421
3JHIUWJFX
2 3 4 5,61
9 8 7
1. Rear storage compartment (page 5-18)
2. Fuel tank cap (page 5-15)
3. Storage compartment B (page 5-18)
4. Windshield (page 5-20)
5. Battery (page 8-28)
6. Fuses (page 8-30)
7. Centerstand (page 8-26)
8. Engine oil level check window (page 8-10)
9. Engine oil ller cap (page 8-10)
