$POUSPMTBOEJOTUSVNFOUT
10
1112
1 2 3 9875 64
1. Rear brake lever (page 5-12)
2. Left handlebar switches (page 5-10)
3. Rear brake uid reservoir (page 8-23)
4. Speedometer (page 5-2)
5. Multi-function display (page 5-3)
6. Tachometer (page 5-3)
7. Front brake uid reservoir (page 8-23)
8. Right handlebar switches (page 5-10)
9. Front brake lever (page 5-12)
10.Throttle grip (page 8-19)
11.Main switch (page 4-7)
12.Auxiliary DC jack (page 5-26)
