Yamaha XMAX - Page 73

8-11

5*1
Skip steps 5–7 if the oil lter element is
not being replaced.
5. Remove the oil lter element cover
by removing the bolts.
6. Remove and replace the oil lter
element and O-ring.
1. Engine oil drain bolt
2. Gasket
1. Bolt
2. Oil lter element cover
12
2
1
7. Install the oil lter element cover
by installing the bolts, then tight-
ening them to the specied
torque.
5*1
Make sure that the O-ring is properly
seated.
8. Install the engine oil drain bolt and
its new gasket, and then tighten
the bolt to the specied torque.
9. Rell with the specied amount of
the recommended engine oil.
5*1
Be sure to wipe off spilled oil on any
parts after the engine and exhaust sys-
tem have cooled down.
NOTICE
ECA24060
.BLF TVSF UIBU OP GPSFJHO NBUFSJBM
FOUFSTUIFDSBOLDBTF
10. Install and tighten the oil ller cap
and its O-ring.
11. Start the engine, and then let it idle
for several minutes while checking
it for oil leakage. If oil is leaking,
1. Oil lter element
2. O-ring
5JHIUFOJOHUPSRVF
Oil lter element cover bolt:
10 N·m (1.0 kgf·m, 7.2 lb·ft)
5JHIUFOJOHUPSRVF
Engine oil drain bolt:
20 N·m (2.0 kgf·m, 15 lb·ft)
3FDPNNFOEFEFOHJOFPJM
See page 10-1.
0JMRVBOUJUZ
Oil change:
1.50 L (1.59 US qt, 1.32 Imp.qt)
With oil lter removal:
1.60 L (1.69 US qt, 1.4
1Imp.qt)
1
2
1FSJPEJDNBJOUFOBODFBOEBEKVTUNFOU
