5-7

Order Job/Part Q’ty Remarks

Removing the camshafts

Timing chain tensioner

Timing chain tensioner gasket

Camshaft caps

Dowel pins

In take camshaft

Exhaust camshaft

Remove the parts in the order listed.

During removal, the dowel pins may still be

connected to the camshaft cap.

For installation, reverse the removal

procedure.

NOTE:

10 Nm (1.0 mkg)

CAMSHAFTS

ENG

CAMSHAFTS
