Yamaha XP500 2001 - Checking the Rear Wheel; Checking the Rear Wheel Drive Hub; Adjusting the Rear Wheel Static Balance

4-13
REAR WHEEL AND BRAKE DISC
CHAS
NOTE:
EAS00565
CHECKING THE REAR WHEEL
1. Check:
 wheel axle
 rear wheel
 wheel bearings
 oil seals
Refer to “FRONT WHEEL”.
2. Check:
 tire
 rear wheel
Damage/wear  Replace.
Refer to “CHECKING THE TIRES” and
“CHECKING THE WHEELS” in chapter 3.
3. Measure:
 rear wheel radial runout
 rear wheel lateral runout
Refer to “FRONT WHEEL”.
EAS00567
CHECKING THE REAR WHEEL DRIVE HUB
1. Check:
 rear wheel drive hub
1
Cracks/damage  Replace.
EAS00575
ADJUSTING THE REAR WHEEL STATIC
BALANCE
 After replacing the tire, wheel or both, the rear
wheel static balance should be adjusted.
 Adjust the rear wheel static balance with the
brake disc and rear wheel drive hub installed.
1. Adjust:
 rear wheel static balance
Refer to “FRONT WHEEL”.
