8-58
SELF-DIAGNOSIS
ELEC
NOTE:
SELF-DIAGNOSIS
The XP500 features a self-diagnosing system for following circuit (-s).
1. Throttle position sensor (TPS)
2. Speed sensor
3. Lean angle cut-off switch
1. ENGINE TROUBLE INDICATOR LIGHT
When the main switch is turned to “ON”, the following items are monitored and the condition codes are
displayed on the engine oil change indicator light (irrespective of whether the engine is running or not).
The XP500 features a self-diagnosing system.
In the XP500, when the main switch is turned on the “Engine oil change indicator light” in the meter
assembly comes on for 0.5 seconds then goes off. However, if there is a malfunction, it comes on for 0.5
seconds, goes off and then begins flashing. (However, it is on while the engine is running.)
Throttle position
sensor (TPS)
Disconnected
Short-circuit
Locked
Enables the motorcycle to
run so that the ignition tim-
ing is fixed when the
throttle is fully opened.
Displays the condition
code on the engine oil
change indicator light.
Blinks in
Fault code [1]
Speed sensor
Illegality pulse
Disconnected
Short-circuit
Displays the condition code
on the engine oil change
indicator light.
Blinks in
Fault code [2]
Lean angle cut-off
switch
Disconnected
Short-circuit
Displays the condition code
on the engine oil change
indicator light.
Blinks in
Fault code [3]
