Yamaha XT225S - Canister (for California Only)

PERIODIC MAINTENANCE AND MINOR REPAIR
6-11
2
3
4
5
6
7
8
9
spark plug threads.
3. Install the spark plug with the
spark plug wrench, and then tight-
en it to the specified torque.
NOTE:
If a torque wrench is not available when
installing a spark plug, a good estimate
of the correct torque is 1/4–1/2 turn
past finger tight. However, the spark
plug should be tightened to the speci-
fied torque as soon as possible.
4. Install the spark plug cap.
EAU19671
Canister (for California only)
This model is equipped with a canister
to prevent the discharging of fuel vapor
into the atmosphere.
● Check each hose connection.
● Check each hose and canister for
cracks or damage. Replace if
damaged.
● Make sure the vent hose is not
blocked. Clean it if necessary.
Tightening torque:
Spark plug:
17.5 Nm (1.75 m·kgf,
12.5 ft·lbf)
1. Fuel tank
2. Carburetor
3. Canister
4. Vent hose
1. Overflow pipe
1
2
3
4
1
