PERIODIC MAINTENANCE AND MINOR REPAIR
6-17
2
3
4
5
6
7
8
9
3. Insert the tailpipe into the muffler,
and then install and tighten the
screw.
NOTE:
Make sure to align the screw holes
when inserting the tailpipe.
EAU21250
Adjusting the carburetor
The carburetor is an important part of
the engine and its emission control sys-
tem, which requires very sophisticated
adjustment. Therefore, carburetor ad-
justments should be left to Yamaha
dealer, who has the necessary profes-
sional knowledge and experience.
EAU21380
Adjusting the throttle cable
free play
The throttle cable free play should mea-
sure 3.0–5.0 mm (0.12–0.20 in) at the
throttle grip. Periodically check the
throttle cable free play and, if neces-
sary, have a Yamaha dealer adjust it.
1. Throttle cable free play
