5-7
CHAS
FRONT WHEEL AND REAR WHEEL
EC5251A1
Rear wheel
1. Install:
9
Bearing (right) 1
9
Circlip 2
9
Spacer 3
9
Bearing (left) 4
9
Oil seal 5
NOTE:
9
Apply the lithium soap base grease on the
bearing and oil seal lip when installing.
9
Install the bearing with seal facing outward.
9
Use a socket that matches the outside diam-
eter of the race of the bearing.
9
Right side of bearing shall be installed first.
9
Install the oil seal with its manufacture’s
marks or numbers facing outward.
cC
Do not strike the inner race of the bearing.
Contact should be made only with the out-
er race.
2. Install:
9
Brake disc 1
9
Bolt (brake disc) 2
NOTE:
Tighten the bolts in stage, using a crisscross
pattern.
9. Install:
9
Hose cover 1
9
Plain washer 2
9
Bolt [hose cover (M8)] 3
9
Bolt [hose cover (M6)] 4
16 Nm (1.6 m•kg, 11 ft•lb)
7 Nm (0.7 m•kg, 5.1 ft•lb)
14 Nm (1.4 m•kg, 1.0 ft•lb)
To Next Page
