2-2. Display and keys
● Display
Fish Analyzer
TM
PRO Ver.1.00
● Symbols and what they mean
Battery level is displayed in 3 levels. Replace when only one (bar) is shown.
It means that the attachment is needed for measurement.
This means it’s a measurement mode for the day after (24hrs) the catch.
If you want to measure on the day of the catch, please select another mode.
It means that the contacts of the sensor electrode are not sufficient.
Use this button to measure the fish.
Press to return to the previous display under setting or measurement mode.
Turn on the device.
Return to the normal screen when setting or measurement mode.
Long press for powering down (off) the device.
Press to display the past measurement results.
Long press for setting options.
Press to select and to finalize the setting option.
Press to display a fish species.
Press to advance to the next display during setting or confirming the measurement
result.
